Tree-based DIF analysis with effect-size classification

Detects Differential Item Functioning (DIF) by recursively splitting the sample on one or more covariates using psychotree::raschtree() (dichotomous data) or psychotree::pctree() (polytomous data), then computes per-split effect-size measures for every item – the Mantel-Haenszel odds-ratio (in the ETS Delta scale) for dichotomous data, or the partial gamma coefficient for polytomous data – and classifies them into ETS A/B/C categories. Optionally, an iterative purification step (Holland & Thayer, 1988; Bjorner et al., 1998) is applied, and tree stability across resamples can be assessed via stablelearner::stabletree().

Usage

RMdifTree(
  data,
  covariates,
  model = c("auto", "PCM", "RM"),
  effect_size = c("auto", "MH", "pgamma"),
  purification = c("none", "iterative"),
  p_adj = c("none", "fdr", "bonferroni"),
  thresholds = c(0.21, 0.31),
  alpha = 0.05,
  prune_negligible = FALSE,
  stability = FALSE,
  stability_B = 100L,
  stability_sampler = c("subsampling", "bootstrap"),
  min_n_per_level = 20L,
  on_rescale = c("message", "warning", "stop"),
  output = c("kable", "dataframe", "tree", "plot"),
  ...
)

Arguments

data

A data.frame or matrix of item responses (non-negative integers, 0-based). One column per item. Items only – pass covariates separately via covariates.

covariates

A data.frame with nrow(data) rows giving the DIF covariates. Columns may be numeric (continuous), factor, ordered factor, or logical. At least one column is required.

model

One of "auto" (default), "PCM", or "RM". "auto" picks RM when the data are dichotomous (max response = 1) and PCM otherwise.

effect_size

One of "auto" (default), "MH" (Mantel-Haenszel), or "pgamma" (partial gamma). "auto" uses MH for RM and partial gamma for PCM.

purification

"none" (default) or "iterative". Iterative purification recomputes the effect size while excluding items already classified as DIF from the matching score (Bjorner et al., 1998).

p_adj

Multiple-testing adjustment for the partial-gamma classification: "none" (default), "fdr" (Benjamini & Hochberg), or "bonferroni". Ignored for MH (which uses the ETS test directly).

thresholds

Numeric length-2 vector with the partial-gamma B/C boundaries (default c(0.21, 0.31)). Ignored for MH (the ETS Delta-scale boundaries 1.0 / 1.5 are used).

alpha

Significance level for the A/C tests. Default 0.05.

prune_negligible

Logical. If TRUE, splits whose every item is classified as A are pruned from the tree. Default FALSE.

stability

Logical. If TRUE, runs stablelearner::stabletree() on the fitted tree to assess variable-selection and cutpoint stability across resamples. Default FALSE.

stability_B

Integer. Number of resamples for stability assessment. Default 100.

stability_sampler

One of "subsampling" (default) or "bootstrap". Subsampling is recommended for tree stability because bootstrap resamples can drop levels of categorical covariates, breaking the model fit on small subsamples.

min_n_per_level

Integer. Minimum count required for any factor level in covariates. Default 20. Set to 0 to disable.

on_rescale

One of "message" (default), "warning", or "stop". Controls how the function reports the situation in which one or more items have no responses in their lowest category within a terminal node of the tree (psychotree silently rescales those items per node, which leaves the per-node item parameters on a different metric). The MH and partial-gamma effect sizes reported here are computed on the raw responses and are not affected. The diagnostic concerns only the per-node item parameters that are visible via plot(tree).

output

One of "kable" (default), "dataframe", "tree", or "plot". "kable" renders the per-split per-item effect-size table as a knitr::kable(); "dataframe" returns the underlying tidy data.frame; "tree" returns the augmented partykit tree object; "plot" returns the partykit tree plot with item names on the terminal-node x-axis (tp_args = list(names = TRUE)). For full control over the plot, use output = "tree" and call plot() on the result with your own tp_args. When stability = TRUE, the stability summary is attached as attr(result, "stability") (a small data.frame) and attr(result, "stability_kable") (pre-rendered kable).

...

Additional arguments forwarded to psychotree::raschtree() or psychotree::pctree(), e.g. minsize, alpha for the parameter-instability test. Note: this alpha (the tree-fitting argument) is independent of the alpha for ETS classification above; pass it via ....

Value

Depending on output:

"kable"

A knitr_kable object with one row per (split node x item), grouped by node via pack_rows-style section headers. The caption summarises model, effect-size measure, purification, and (if requested) stability.

"dataframe"

A data.frame with one row per (split node x item): columns NodeID, Split (human-readable description of the split), Variable, Direction, Item, EffectSize, SE, Class (A/B/C), Flagged (TRUE for B or C), n_left, n_right.

"tree"

The fitted partykit tree object with class c("RMdifTree", ...), with effect-size results stored at tree$info$effectsize.

"plot"

A plotted partykit tree.

Stability results (when stability = TRUE) are attached to the return value as attr(result, "stability") (data.frame) and attr(result, "stability_kable") (pre-rendered kable).

Details

Continuous covariates (e.g., age in years) and interactions among multiple covariates are handled natively by the model-based recursive-partitioning machinery of partykit / psychotree.

ETS Delta-scale Mantel-Haenszel. The MH common odds ratio \(\hat{\alpha}_{MH}\) is mapped to the ETS Delta scale via \(\Delta_{MH} = -2.35 \log \hat{\alpha}_{MH}\). The classification rules (Holland & Thayer, 1988; Zwick, 2012) are:

• Class A: \(|\Delta_{MH}| < 1\) or test of \(\Delta_{MH} = 0\) not rejected at alpha.

• Class C: \(|\Delta_{MH}| \ge 1.5\) and test of \(|\Delta_{MH}| \le 1\) rejected at alpha.

• Class B: otherwise.

easyRasch2 uses the sign convention of effecttree: positive \(\Delta\) indicates that the item is more difficult for the second (reference) group.

Partial gamma. iarm::partgam_DIF() provides the gamma estimate and SE per item. ETS-style classification follows Bjorner et al. (1998): A if \(|\gamma| < 0.21\) or the test of \(\gamma = 0\) is not rejected at alpha; C if \(|\gamma| > 0.31\) and the test of \(|\gamma| \le 0.21\) is rejected at alpha; B otherwise.

Continuous and interaction effects. The recursive partitioning step automatically handles continuous covariates (the parameter-instability test searches for the optimal cutpoint) and multivariate interactions (later splits are conditional on earlier ones). To assess sensitivity of variable selection and cutpoints to the particular sample, set stability = TRUE.

Stability assessment. When stability = TRUE, the same tree-fitting call is replayed on stability_B resamples of the data. The returned stabletree object reports, per covariate, the proportion of resamples in which it was selected at any split, and (for continuous covariates) the empirical distribution of cutpoints. Stability is independent of effect-size classification – a stable split with a negligible effect is still negligible, and a large effect on an unstable split should be interpreted with care. Cost is roughly stability_B times the original fitting time.

Acknowledgement. The effect-size machinery – MH and partial gamma per node, iterative purification, ETS A/B/C classification – follows the implementations by Henninger & Radek in the GitHub packages raschtreeMH and effecttree. The relevant code has been adapted here under the MIT licence (see file header).

References

Bjorner, J. B., Kreiner, S., Ware, J. E., Damsgaard, M. T., & Bech, P. (1998). Differential item functioning in the Danish translation of the SF-36. Journal of Clinical Epidemiology, 51(11), 1189-1202. doi:10.1016/S0895-4356(98)00111-5

Henninger, M., Debelak, R., & Strobl, C. (2023). A new stopping criterion for Rasch trees based on the Mantel-Haenszel effect size measure for DIF. Educational and Psychological Measurement, 83, 181-212. doi:10.1177/00131644221077135

Henninger, M., Radek, J., Debelak, R., & Strobl, C. (2025). Partial credit trees meet the partial gamma coefficient for quantifying DIF and DSF in polytomous items. Behaviormetrika, 52, 221-257. doi:10.1007/s41237-024-00252-3

Philipp, M., Rusch, T., Hornik, K., & Strobl, C. (2018). Measuring the stability of results from supervised statistical learning. Journal of Computational and Graphical Statistics, 27, 685-700. doi:10.1080/10618600.2018.1473779

See also

RMdifLR, RMdifGamma

Examples

# \donttest{
if (requireNamespace("psychotree", quietly = TRUE) &&
    requireNamespace("partykit", quietly = TRUE) &&
    requireNamespace("difR", quietly = TRUE) &&
    requireNamespace("iarm", quietly = TRUE)) {
  data("DIFSimPC", package = "psychotree")

  items <- as.data.frame(as.matrix(DIFSimPC$resp))
  covs  <- DIFSimPC[, c("age", "gender", "motivation")]

  # Default: kable of per-split effect sizes
  RMdifTree(items, covariates = covs)

  # Tidy data.frame -- one row per (split node x item)
  df <- RMdifTree(items, covariates = covs, output = "dataframe")
  df[df$Flagged, ]

  # Tree object (for plotting via partykit::plot)
  tree <- RMdifTree(items, covariates = covs, output = "tree")
  plot(tree)

  # Stability assessment refits the tree on B resamples.
  # (use more resamples, e.g. 100+, in real analyses)
  if (requireNamespace("stablelearner", quietly = TRUE)) {
    kbl <- RMdifTree(items, covariates = covs,
                     purification = "iterative", p_adj = "fdr",
                     stability = TRUE, stability_B = 25)
    kbl                          # main effect-size kable
    attr(kbl, "stability_kable") # pre-rendered stability kable
    attr(kbl, "stability")       # raw stability data.frame
  }
}

#> Error in root.matrix(switch(vcov, opg = chol2inv(chol(meat)), info = bread,  :
#>   Matrix is not positive semidefinite
#> Error in root.matrix(switch(vcov, opg = chol2inv(chol(meat)), info = bread,  :
#>   Matrix is not positive semidefinite
#> Stability assessment notes (suppressed during fitting): 137 'minimum score not zero' rescaling warning(s); 21 'items with null categories' warning(s). These reflect sparsity in some resamples and are normal sampling variability; selection-frequency and cutpoint summaries are based on resamples that completed successfully.
#>     Variable    Type Selected_orig Selection_freq_pct Cutpoint_mean Cutpoint_sd
#> 1        age numeric          TRUE                100       42.9706      8.1556
#> 2     gender  factor          TRUE                100            NA          NA
#> 3 motivation ordered         FALSE                  4            NA          NA
# }
